Battery Cells

LiFePO4 Long Cycle Life Battery 3.2V96Ah

Item No.: IFP27175200A-96Ah
LiFePO4 Long Cycle Life Battery 3.2V96Ah
Description
Item Specification Remark
Model BA27175200A-96Ah
Type Prismatic
Material LiFePO4
Nominal Voltage 3.2 V
Nominal Capacity 96Ah @25℃
Energy 307.2Wh
Energy Density 150Wh/kg
Charge Voltage 3.65 V
Discharge End Voltage 2 V
Standard Charge Current 96A 1C
Max Continuous Charge Current 192A 2C
Standard Discharge Current 96A 1C
Max Continuous Discharge Current 288A 3C
Peak Discharge Current 5C 10S
Charge Temp. Range 0~50 ℃
Discharge Temp. Range -20~60 ℃
Storage Temp. Range -10~30 ℃
Dimension 42*100*140 mm
Weight 2060g
Cycle life 6000 times @1C/1C 100%DOD
